Working principle of intelligent tomato beater
Time：2021-04-07 14:36 Browse：277
The working principle of automatic tomato beating machine
Automatic tomato beater: the motor is driven by belt to make the scraper mounted on the spline rotate at high speed. When the broken raw fruit enters the machine through the feed port, the slurry receiving plate will evenly send the materials to the scraper and screen. Because of the reverse action of scraper and the existence of lead angle, the material moves along the cylinder to the outlet end. The moving track is spiral, and the material is scratched by centrifugal force during the moving process between the scraper and screen cylinder. The juice and meat (already slurry) are sent to the next process through the sieve hole. (double beater is used to repeat the previous process in linkage). The leather and seeds are sent out from the screen The slag hopper is discharged to reach the intention of active separation. Only changing the screen of different standards and adjusting the size of the guide angle of scraper can change the different beating speed to achieve the satisfying effect.
The application scope of the automatic tomato beater of Jingjiang Weineng machinery
The automatic tomato beating machine is suitable for beating and separating tomato, kiwi fruit, strawberry, apple, pear and hawthorn and jujube after being crushed.
Characteristics of automatic tomato beater:
1. The slurry and slag are separated automatically.
2. It can be combined in production line and can be produced by single machine.
3. Stainless steel SUS304 is made of material, which conforms to food hygiene.
