Introduction to the special use and cleaning sequence of dru
Time：2020-11-11 07:10 Browse：277
1、 Features of drum cleaning machine:
1. The cleaning tank is made of stainless steel, acid and alkali resistant, beautiful and durable, reinforced and welded;
2. The vibration plate is welded with thickened stainless steel, with good sealing performance and hard chromium plating treatment, which is durable;
3. High efficiency Q-value vibrator, the fourth generation of ultrasonic generator is selected, and the ultrasonic power is adjustable;
4. "PLC" programmable control system and electronic components imported from Japan;
5. Touch LCD touch screen control, cleaning time and parameters can be adjusted;
6. The ultrasonic generator and the vibrating plate are of split structure and connected with high-frequency wire, which is convenient for maintenance;
7. The cleaning tank is equipped with water level maintenance, circulating filtering system, heating system and serrated overflow;
8. Cleaning tank and dry tank are equipped with current overload maintenance and phase loss maintenance;
9. The cleaning tank is equipped with swing system, which can clean quickly and evenly;
10. Full active control, simple and convenient operation.
2、 Basic structure of equipment:
The whole machine is a fully enclosed structure. The tank body of the machine body is stainless steel structure. The outer cover of the machine body is carbon steel spray plate and equipped with plexiglass observation window. Main components of the equipment: ultrasonic cleaning host part, multi arm lifting manipulator, multi arm transverse moving manipulator, electrical control cabinet, active feeding table, active discharging table, clean liquid storage tank, dirty liquid storage tank, distillation recovery machine, refrigeration system.
3、 Cleaning process of drum cleaning machine:
Feeding → hot dip washing (rotating) → ascending desalting (rotating) → upper ultrasonic fine washing (rotating) → ascending desolvation (rotating) → ultrasonic fine washing (rotating) → ascending desalting (rotating) → steam bath washing (rotating) → rising freezing drying (rotating) → discharging
4、 Main uses of drum type cleaning machine:
Cleaning of electronic parts, degreasing and rust removal before electroplating, cleaning after electroplating, hardware cleaning, oil removal and cleaning of clock and watch parts, degreasing and cleaning of watch strap, degreasing and cleaning of mechanical parts, cleaning of things, optical lens cleaning, jewelry cleaning, toy cleaning, glasses cleaning, stainless steel tableware degreasing and cleaning, computer case degreasing and cleaning, LCD outer box removing Oil, cleaning, automobile fine parts and fine casting parts oil, chip, cleaning, etc.
